equalize

Built-in command

Arguments:

_nb_levels[%]>0,_value_min[%],_value_max[%] or
(no arg)

Description:

Equalize histograms of selected images.

If value range is specified, the equalization is done only for pixels in the specified
value range.

Default values:

nb_levels=256, value_min=0% and value_max=100%.

Examples of use:

• Example #1

<a href="image.jpg" class="highslide" onclick="return hs.expand(this)">image.jpg</a> +equalize

Command: <a href="image.jpg" class="highslide" onclick="return hs.expand(this)">image.jpg</a> +equalize

Command: <a href="image.jpg" class="highslide" onclick="return hs.expand(this)">image.jpg</a> +equalize

• Example #2

<a href="image.jpg" class="highslide" onclick="return hs.expand(this)">image.jpg</a> +equalize 4,0,128

Command: <a href="image.jpg" class="highslide" onclick="return hs.expand(this)">image.jpg</a> +equalize 4,0,128

Command: <a href="image.jpg" class="highslide" onclick="return hs.expand(this)">image.jpg</a> +equalize 4,0,128
